Buhler Pellet Ring Die
Name: Buhler 350 ring die, Buhler 400 pellet die, Buhler 420 feed pellet machine ring die, Buhler 520 feed pellet die, Buhler 660 feed pellet mill die, Buhler pellet machine matrix and Buhler pellet machine roller.
Model: Buhler350, Buhler400, Buhler420, Buhler520, Buhler660, Buhler 900...
Raw material:
Ring die: alloy steel 20CrMnTi, stainless steel X46Cr13.
Roller: alloy steel 40Cr or 20CrMnTi (Chinese standard), 20MnCr5 (Germany standard), 100Cr6 (bearing steel).Hole diamter: φ1mm-φ14mm.
Compression ratio: 1:2-1:28.
Processing machines:
20 sets auto gun-drilling machines(3 sets deepth holes drilling machines, can drill max 140mm thickness holes, can drill min 1.0mm diameter holes).
6 sets auto counter-sinking machines.
6 sets auto CNC lathing machines.
2 sets vacuum heat treatment machines.
Delivery time: mostly 10-35 days.
Packing way: wooden box.
Accept customized!!!
Model:
Buhler 520.138 (DPBA) fertilizer pellet ring die:
Buhler 520.178(DPBS) pelletizer matrix:
Buhler 660.178(DPAA) pellet pressing die:
Buhler 660.228(DPAS) pelleting die:
Buhler 660.265(DPHD) feed ring die:
Buhler pellet machine roller:
|
